SMART-603CNC-6S / 8S

SMART-603CNC-6S/8S is the 600 kN all-in-one machine fitted with a six or eight station punching turret. Capacity matches the single-station machine at 260 × 16 mm for punching and cutting and 260 × 20 mm flatwise, with the turret removing the manual tool change between hole diameters. On drawing-driven work carrying four or five hole sizes, tool changing is typically the largest non-cutting element of cycle time. Bending accuracy is ±0.2° and installed power is 12.6 kW.

• Beiene 3D intelligent control centre
• Turret punching unit, 6 or 8 stations
• Reads 3D and 2D drawings directly — no re-drawing step
• Fully automatic CNC bending
• Bend sequence simulation before the first part
• AIRLINK real-time drawing and file sharing between office and machine
• Flatwise and edgewise bending, twisting, embossing, cable lug forming, Z and U bends, shearing and punching

Is the turret justified over the single station?

It is, on high-mix work. The turret removes the manual tool change between hole sizes, which on a drawing-driven job with four or five hole diameters is usually the single largest non-cutting time on the machine.
